A Performance Catrike loaded with fun. It can corner like its on rails and it is still capable of light touring and commuting.
Model Details
| Standard Colors |
Gallery |
| Graphite, Orange |
|
Technical Specs
| Frame & Geometry |
| Frame |
Space Frame made from strong and lightweight Aluminium |
| Total Length |
6' 3" (1.91 m) |
| Total Width |
31 1/2" (800 mm) |
| Total Height |
22" (559 mm) |
| Bracket Height |
16" (406 mm) |
| Seat Angle |
29° Ergo Seat (from horizontal) |
| Seat Height |
7" (178 mm) |
| Seat Width |
14" (355 mm) |
| Wheel Base |
39" (991 mm) |
| Wheel Track |
27 1/2" (699 mm) |
| Turning Circle |
16' 6" (5.03 m) |
| Turning Radius |
8' 1/4" (2.52 m) |
| Ground Clearance |
2 1/4" (57 mm) |
| Front Wheels |
349 (16") |
| Rear Wheel |
451 (20") |
| Weight |
30 lbs (13.6 kg) |
| Rider Weight Limit |
275 lbs (125 kg) |
| Components* |
| Brakes |
Avid BB7 Disc Brakes |
| Brake Levers |
Avid FR5 Flat Pull Levers |
| Front Derailleur |
Microshift |
| Rear Derailleur |
SRAM X7 |
| Shifters |
SRAM X7 |
| Crankset |
Truvativ Touro 165mm Triple |
| Bottom Bracket |
Truvativ GXP |
| Chainrings |
30/42/52 |
| Chainring Guard |
Economy Guard |
| Cassette |
SRAM PG 950 9-SPD 11-32 |
| Chain |
KMC X9 |
| Idler |
TerraCycle |
| Headsets |
Cane Creek |
| Front Tires |
Schwalbe Kojak |
| Rear Tire |
Schwalbe Durano |
| Features & Accessories |
| Space Neck Rest |
| Flag Mount & Flag |
| Rear View Mirror |
| Combination Platform/Clipless Pedals |
| Computer Sensor Mount |
| Brake Lever Velcro Strap for Parking |
| No Brake Steer |
| Self Centering |
| Ackerman Steering Compensation |
| Structural Front Boom |
| Quick-Release Indexing Boom Clamp |
| Ergo Seat |
| Double Bend Frame |
| Aluminium Rod Ends |
| Low Friction PTFE Chain Tube |
