A Premium multi-purpose Catrike. It is great for the trail, commuting or touring the World.
Model Details
| MSRP |
Standard Colors |
Gallery |
| $2,350 |
Silver, Blue |
|
Technical Specs
| Frame & Geometry |
| Frame |
Space Frame made from strong and lightweight Aluminium |
| Total Length |
6' 2" (1.88 m) |
| Total Width |
33" (838 mm) |
| Total Height |
24" (610 mm) |
| Bracket Height |
15" (381 mm) |
| Seat Angle |
37° Ergo Seat (from horizontal) |
| Seat Height |
8" (203 mm) |
| Seat Width |
14" (355 mm) |
| Wheel Base |
39" (991 mm) |
| Wheel Track |
29" (737 mm) |
| Turning Circle |
16' (4.88 m) |
| Turning Radius |
8' (2.44 m) |
| Ground Clearance |
3" (76 mm) |
| Front Wheels |
406 (20") |
| Rear Wheel |
406 (20") |
| Weight |
33 lbs (15 kg) |
| Rider Weight Limit |
275 lbs (125 kg) |
| Components* |
| Brakes |
Avid BB7 Disc Brakes |
| Brake Levers |
Avid FR5 Flat Pull Levers |
| Front Derailleur |
Microshift |
| Rear Derailleur |
SRAM X7 |
| Shifters |
SRAM SX7 |
| Crankset |
Truvativ Touro 165mm Triple |
| Bottom Bracket |
Truvativ BB Power Spline |
| Chainrings |
30/42/52 |
| Chainring Guard |
Economy Guard |
| Cassette |
SRAM PG 950 9-SPD 11-32 |
| Chain |
KMC X9 |
| Idler |
TerraCycle |
| Headsets |
Cane Creek |
| Front Tires |
Schwalbe Marathon Racer |
| Rear Tire |
Schwalbe Marathon Racer |
| Features & Accessories |
| Space Neck Rest |
| Flag Mount & Flag |
| Rear View Mirror |
| Combination Platform/Clipless Pedals |
| Computer Sensor Mount |
| Brake Lever Velcro Strap for Parking |
| No Brake Steer |
| Self Centering |
| Ackerman Steering Compensation |
| Structural Front Boom |
| Quick-Release Indexing Boom Clamp |
| Ergo Seat |
| Double Bend Frame |
| Aluminium Rod Ends |
| Low Friction PTFE Chain Tube |
