A High Quality Catrike for Well Behaved Kids!
Model Details
| Standard Colors |
Gallery |
| Orange |
|
Technical Specs
| Frame & Geometry |
| Frame |
Space Frame made from strong and lightweight Aluminium |
| Total Length |
5' 3" (1.6 m) |
| Total Width |
31 1/2" (800 mm) |
| Total Height |
20 1/4" (515 mm) |
| Bracket Height |
13 1/2" (342 mm) |
| Seat Angle |
43° Seat (from horizontal) |
| Seat Height |
8 1/2" (215 mm) |
| Seat Width |
12" (305 mm) |
| Wheel Base |
33 1/2" (851 mm) |
| Wheel Track |
27 1/2" (699 mm) |
| Turning Circle |
13' 8" (4.17 m) |
| Turning Radius |
6' 10" (2.09 m) |
| Ground Clearance |
2 3/4" (70 mm) |
| Front Wheels |
349 (16") |
| Rear Wheel |
406 (20") |
| Weight |
28 lbs (12.75 kg) |
| Rider Weight Limit |
225 lbs (102 kg) |
| Components* |
| Brakes |
Avid BB5 Disc Brakes |
| Brake Levers |
Avid FR5 Flat Pull Levers |
| Front Derailleur |
N/A |
| Rear Derailleur |
SRAM SX5 |
| Shifters |
SRAM SX5 Half Pipe Rear Shifter |
| Crankset |
Kids 152mm |
| Bottom Bracket |
Truvativ BB Power Spline |
| Chainrings |
36T |
| Chainring Guard |
Economy Guard |
| Cassette |
SRAM PG 950 9-SPD 11-32 |
| Chain |
KMC X9 |
| Idler |
TerraCycle |
| Headsets |
Cane Creek |
| Front Tires |
Schwalbe Marathon |
| Rear Tire |
Schwalbe Marathon Racer |
| Features & Accessories |
| Flag Mount & Flag |
| Rear View Mirror |
| Brake Lever Velcro Strap for Parking |
| No Brake Steer |
| Self Centering |
| Ackerman Steering Compensation |
| Structural Front Boom |
| Indexing Boom Clamp |
| Aluminium Rod Ends |
| Low Friction PTFE Chain Tube |
