World Class Performance and Handling.
Musashi Introduction Video
Model Details
| Standard Colors |
Gallery |
| White, Black |
|
Technical Specs
| Frame & Geometry |
| Frame |
Space Frame made from strong and lightweight Aluminium |
| Total Length |
6' 6" (1.98 m) |
| Total Width |
22" (559 mm) |
| Total Height |
34 1/2" (876 mm) |
| Bracket Height |
25" (635 mm) |
| Seat Angle |
29° Ergo Seat (from horizontal) |
| Seat Height |
15" (381 mm) |
| Seat Width |
10" (254 mm) |
| Wheel Base |
51" (1295 mm) |
| Wheel Track |
N/A |
| Turning Circle |
N/A |
| Turning Radius |
N/A |
| Ground Clearance |
10" (254 mm) |
| Front Wheels |
451 (20") |
| Rear Wheel |
700c (29") |
| Weight |
27 lbs (12.25 kg) |
| Rider Weight Limit |
225 lbs (102 kg) |
| Components* |
| Brakes |
Tektro Road Calliper Brakes |
| Brake Levers |
Avid FR5 Flat Pull Levers |
| Front Derailleur |
SRAM Rival |
| Rear Derailleur |
SRAM Rival Midcage 10-SPD |
| Shifters |
SRAM TT500 10-SPD |
| Crankset |
SRAM Rival 10SP 165mm |
| Bottom Bracket |
SRAM Rival GXP Team |
| Chainrings |
34/50 |
| Chainring Guard |
Super Guard 110BCD |
| Cassette |
SRAM Rival 10-SPD 11-32 |
| Chain |
KMC 10-SPD DX10SC |
| Idler |
TerraCycle |
| Headsets |
Cane Creek |
| Front Tire |
Schwalbe Durano |
| Rear Tire |
Schwalbe Durano |
| Features & Accessories |
| Space Neck Rest |
| Rear View Mirror |
| Combination Platform/Clipless Pedals |
| Carbon Fibre Front Fork |
| Brake Lever Velcro Strap for Parking |
| Self Centering |
| Structural Front Boom |
| Indexing Boom Clamp |
| Ergo Seat |
| Double Bend Frame |
| Low Friction PTFE Chain Tube |
